Product Description
| Usage/Application |
Industrial |
| Material |
Stainless Steel |
| Brand |
Champion |
| Filler Material |
Compressed Asbestos Fibre |
| Maximum Temperature |
440 Degree C |
| Tolerance |
+-0.125 mm |
Description:
Champion Spiral Wound Gaskets are composed of a metallic continuous strip with a special shaped profile, coupled with a continuous filling strip (Asbestos, PTFE, Graphite etc.) evenly wound in concentric spiral under constant stress. The Spiral Wound Gaskets are reinforced on the inner and outer diameter by winding of several electrically welded metal. The main property of Spiral Wound Gasket, owing to elastic action of the special metallic strip profile, is that of offering a perfect sealing under fluctuating pressure and temperature conditions & maintaining tight elastic recovering. This elasticity can be modified by a proper selection of components. A proper selection of materials (both metal and fillers) allows the spiral gasket to accommodate the most varied operating conditions. Spiral Gaskets are made as per ASME B16.20 to suit ASME B16.5 flanges and as per "A" Series and "B" Series to suit ASME B16.47 flanges. We also make spiral as per DIN 2632-2638, IS Standards, etc.
Request
Callback
Ye
Reliable Sealing Solutions for IndustryChampion Compressed Asbestos Fiber Spiral Wound Gaskets provide outstanding sealing solutions for complex industrial systems. Manufactured with meticulous attention to quality, these ring-shaped gaskets accommodate various machinery and piping, delivering consistent performance in high-stress environments. Whether used in chemical, petrochemical, or power generation sectors, they effectively prevent leakages while withstanding challenging operating conditions.
Comprehensive Range Available Across IndiaAs a leading distributor, supplier, and trader based in India, we supply Champion gaskets in all standard sizes and colors to meet diverse industrial needs. Our wide inventory and efficient logistics network ensure prompt delivery and availability nationwide, supporting your maintenance schedules and minimising downtime.
FAQ's of Champion Compressed Asbestos Fiber Spiral Wound Gasket:
Q: How are Champion Compressed Asbestos Fiber Spiral Wound Gaskets typically used in industrial applications?
A: These gaskets are commonly utilized as ring gaskets in piping systems, flanges, valves, and equipment that require dependable sealing against high pressures, temperatures, and corrosive substances.
Q: What is the process involved in installing a Champion Spiral Wound Gasket?
A: Installation typically requires cleaning the flange surfaces, ensuring correct alignment, and carefully placing the ring gasket. Bolts are then tightened gradually in a star pattern to achieve even compression and an optimal seal.
Q: When should these gaskets be replaced to maintain equipment safety?
A: It is advisable to replace the gasket during routine maintenance, or at the first sign of wear, leakage, or reduced sealing efficiency to ensure continuous equipment safety and peak performance.
Q: Where can I source genuine Champion Compressed Asbestos Fiber Spiral Wound Gaskets in India?
A: You can obtain authentic Champion gaskets through authorized distributors, suppliers, and traders who operate across India, guaranteeing quality and support for industrial requirements.
Q: What benefits do felt material gaskets offer compared to other gasket materials?
A: Gaskets made from felt offer excellent sealing properties, flexibility, and resilience, making them ideal for applications requiring both durability and adaptability to surface irregularities.
Q: How does the color variety support industrial users?
A: The availability of gaskets in all colors allows for efficient visual identification, inventory organization, and the assignment of specific gaskets to particular processes or media, enhancing safety and system management.
