Product Description
We are a leading Wholesale Supplier of champion graphite spiral wound gasket, champion polytetrafluoroethylene spiral wound gasket, champion af159 oil fibre jointing sheet, champion af160 acid fibre jointing sheet, champion af110 water fiber jointing sheet and champion compressed asbestos fiber spiral wound gasket from Pune, India.
|
|
|
|
Champion |
| Usage/Application |
Industrial |
| Filter Material |
Graphite |
| Tolerance |
+-0.125 mm |
| Maximum Temperature |
550 Degree C |
| Winding Material |
Stainless Steel |
Description:Champion Spiral Wound Gaskets are composed of a metallic continuous strip with a special shaped profile, coupled with a continuous filling strip (Asbestos, PTFE, Graphite etc.) evenly wound in concentric spiral under constant stress. The Spiral Wound Gaskets are reinforced on the inner and outer diameter by winding of several electrically welded metal. The main property of Spiral Wound Gasket, owing to elastic action of the special metallic strip profile, is that of offering a perfect sealing under fluctuating pressure and temperature conditions & maintaining tight elastic recovering. This elasticity can be modified by a proper selection of components. A proper selection of materials (both metal and fillers) allows the spiral gasket to accommodate the most varied operating conditions. Spiral Gaskets are made as per ASME B16.20 to suit ASME B16.5 flanges and as per "A" Series and "B" Series to suit ASME B16.47 flanges. We also make spiral as per DIN 2632-2638, IS Standards, etc.Durable and Versatile MaterialsChampion gaskets are made from advanced materials like non-asbestos fibers, graphite, PTFE, rubber, and metallic blends. These materials grant exceptional tensile strength and resistance to harsh media, including acids, bases, solvents, and chemicals. The product range includes both smooth and textured surface finishes, and customized compositions can be provided for special applications.
Comprehensive Design OptionsThe gaskets are available in plain, spiral wound, jacketed, and ring styles to accommodate varied industrial sealing needs. Shapes and sizes can be customized to fit round, oval, or complex designs, with thicknesses from 0.4 mm to 5 mm. Optional inner and outer rings can be tailored according to material and dimension specifications required for enhanced sealing performance.
FAQs of Champion Gasketing Products:
Q: How do Champion Gasketing Products ensure corrosion resistance?
A: Champion gaskets utilize materials such as non-asbestos fibers, graphite, PTFE, rubber, and metallic blends that offer excellent resistance to acids, bases, solvents, and other aggressive chemicals, ensuring reliable performance even in harsh industrial environments.
Q: What types of applications are these gaskets best suited for?
A: These gaskets are designed for sealing joints in pipes, flanges, engines, and various industrial equipment. Their durability and minimal leakage rate make them ideal for use in settings with steam, oils, gases, chemicals, and demanding mechanical conditions.
Q: When should I opt for a custom-designed gasket from Champion?
A: Custom gasket designs are recommended when standard sizes, shapes, or materials do not meet the specific requirements of your equipment or application. Champion offers customization in dimension, ring materials, shape, and finish to guarantee optimal sealing and compatibility.
Q: Where can I use Champion gaskets considering their working temperature range?
A: Champion gaskets can be employed in environments ranging from -40C up to 600C, making them suitable for processes involving extreme heat or cold in chemical plants, refineries, manufacturing units, and other industries with variable temperature conditions.
Q: What is the process for ordering these gaskets as a distributor or supplier in India?
A: Distributors, suppliers, and traders can contact Champion directly with their requirementsspecifying dimensions, materials, shape, and designafter which the manufacturing process begins in accordance with industrial standards, leading to timely delivery of both standard and custom gaskets.
Q: How does the low compression set and strong fibre matrix benefit sealing performance?
A: A low compression set ensures that the gasket maintains its shape and sealing capability over repeated cycles, while the reinforced fiber matrix delivers robust tensile strength and enhances the durability of the gasket under high pressure and mechanical stress.
Q: Which standards do Champion gaskets conform to?
A: Champion gaskets are manufactured to comply with established industrial standards, including IS, ASTM, and DIN. This guarantees reliability, compatibility, and quality assurance for critical sealing applications across industries.
