Product Description
Champion AF110 Water Fiber Jointing Sheet
|
Model Name/Number
|
AF110
|
|
Color
|
Red
|
|
Usage/Application
|
Industrial
|
|
Brand
|
Champion
|
|
Max. Operating Pressure
|
25 bar
|
|
Density
|
1.75 g/cm
|
|
Tensile Strength
|
7 Mpa
|
|
Compressibility
|
8%
|
|
Water Absorpation
|
less than or equal 5%
|
|
Ignition Loss
|
less than or equal 40%
|
Product Description
A cost effective product manufactured from ecofriendly natural cellulosic fibres bonded with suitable mix of elastomers.
Available Colour:
Red and Green
Service Conditions:
General purpose gasketing material suitable for use with Oils, Solvents, Gases, Water, L.P.Steam and most dilute acids and alkalies (Low service conditions).
Request
Callback
Exceptional Temperature and Pressure EnduranceChampion AF110 Water Fiber Jointing Sheet withstands temperatures up to 200C and pressures up to 20 bar, making it suitable for both water and steam sealing. Its high durability ensures dependable operation in rigorous utility and process piping systems, giving industries peace of mind against leaks and seal failures.
Precision to Global StandardsEngineered to meet BS 7531 specifications, Champion AF110 guarantees consistent quality and performance. Its hardness range of 70-90 Shore A and customizable thickness from 0.5mm to 5mm allow tailored solutions to meet diverse industrial sealing requirements for gaskets and flanges.
FAQ's of Champion AF110 Water Fiber Jointing Sheet:
Q: How is the Champion AF110 Water Fiber Jointing Sheet used in sealing applications?
A: Champion AF110 sheets are typically cut into gaskets and placed between flanges or other surfaces to prevent the leakage of water or steam. Their fibrous structure and high hardness provide a durable seal even in environments with high pressure and temperature.
Q: What benefits does the Champion AF110 offer over conventional jointing materials?
A: The AF110 offers superior resistance to temperature (up to 200C) and pressure (up to 20 bar), along with compliance to BS 7531 standards. Its wide thickness range, robust hardness, and excellent seal reliability make it a preferred solution for industrial water and steam sealing.
Q: When should I select the 0.5mm or 5mm thickness for my sealing project?
A: Choose thinner sheets (0.5mm) for smooth, precise flange surfaces and applications with minimal surface irregularities. Thicker sheets, such as 5mm, are ideal for sealing rough or uneven surfaces where a greater gasket material is needed to fill gaps and ensure a proper seal.
Q: Where can I source the Champion AF110 Water Fiber Jointing Sheet in India?
A: Champion AF110 jointing sheets are available through authorized distributors, suppliers, and traders across India. For the best fit and service, contact recognized industrial sealing material providers in your region.
Q: What is the process for installing a Champion AF110 Water Fiber Jointing Sheet?
A: Installation involves selecting the appropriate sheet thickness, cutting the sheet to the desired gasket shape, and positioning it accurately between clean, dry flange surfaces before tightening the bolts evenly to the specified torque.
Q: What are the typical usage areas for this jointing sheet?
A: Champion AF110 is commonly used in water and steam sealing for pipelines, boilers, pumps, and industrial equipment, especially where reliability under moderate to high temperatures and pressures is critical.
