Product Description
| Color | BROWN/GREY |
| Usage/Application | Industrial |
| Brand | Champion |
| Model Number | 51 HIGH PRESSURE |
| Max. Temperature | 440 Degree C |
| Max. Pressure | 80 Kg/sq.cm |
Description:
Manufactured from selected Asbestos Fibre and bonded with high grade binder compound, this product has a wide range of applications in the industrial field. Recommended against steam, neutral non flammable gases, dyes alkalies, fats, oils, alcohols, motor fuels and such other engineering service conditions which do not warrant the use of as High Grade material such as CHAMPION Style 54 SUPER.
Available Colour:
Brown/grey or Graphited Finish Metallic and Non-metallic
Exceptional Sealing PerformanceChampion 51 jointing sheets and gaskets are formulated for high-pressure scenarios, delivering reliable sealing even at extreme temperatures and pressures. Their unique blend of compressed asbestos fibers and binders ensures durability, precise recovery, and outstanding mechanical strength, making them a preferred choice across diverse industries.
Versatile Application SpectrumEngineered to seal various mediumsincluding water, saturated steam, hydrocarbons, oils, chemicals, acids, alkalis, and gasesthese sheets suit general and specialized industrial sealing needs. They excel in flanged joints, pipelines, boilers, heat exchangers, and valve covers, accommodating both standard and custom gasket requirements.
Customizable Solutions and OEM ServiceChampion 51 sheets are available in a standard 1500 mm x 1500 mm format and customizable for shapes and sizes. OEM support ensures tailored solutions for specific industry requirements, while options for inner or outer rings enhance sealing integrity in critical systems.
FAQs of Champion 51 High Pressure Compressed Asbestos Fiber Jointing Sheet And Gasket:
Q: How can Champion 51 High Pressure Jointing Sheets and Gaskets be used in industrial applications?
A: These sheets and gaskets provide high-integrity sealing for flanged joints, pipelines, boilers, and heat exchangers in industries such as petrochemical, power generation, oil and gas, chemical processing, and steam systems.
Q: What process is involved in customizing a gasket from the Champion 51 jointing sheet?
A: To customize a gasket, manufacturers cut the Champion 51 sheets to specific dimensions and shapes according to client requirements. Options like inner and outer rings can be added upon request for enhanced sealing.
Q: When should I choose Champion 51 over other gasket materials?
A: Champion 51 is ideal when you require sealing solutions capable of withstanding high pressures (up to 115 bar) and temperatures (up to 450C), as well as resistance to a broad range of fluids including steam, oils, chemicals, and gases.
Q: Where are Champion 51 gaskets and sheets typically supplied or used?
A: They are distributed, supplied, and traded primarily across industrial sectors in India, and are used extensively in settings that demand reliable, durable jointingsuch as refineries, engineering plants, and utility companies.
Q: What are the benefits of using Champion 51 asbestos fiber jointing sheets?
A: Champion 51 sheets deliver excellent compressibility and recovery, high mechanical strength, resistance to aggressive media, and stability in extreme environments, ensuring long-lasting and leak-proof performance.
Q: How do the performance standards for Champion 51 compare internationally?
A: These products conform to IS 2712/1998 Grade 1, ASTM F104, and BS 2815, ensuring compatibility with global industrial requirements and reliability in various operational environments.
